Easy to maintain and with good performance
Item No :
LTCZ100-850Order(MOQ) :
1 SETPayment :
T/TProduct Origin :
BENGBU,ANHUIColor :
BLUE，CUSTOMIZATIONShipping Port :
SHANGHAILead Time :
AROUND 30-45 DAYSWeight :
800
PRODUCT DESCRIPTION
1.The cam mechanism drives the folding machine to fold the upper and lower blades, completing the folding of filter media through the alternating action of the upper and lower blades.The overlapping height of the two blades equals the folding height of the filter media.
2.The front platform of the folding machine is equipped with a folding dot counting device. The dotter marks the filter material during the folding process by applying dots according to the preset fold count.
3.The pre-compression function can be applied to a wider range of materials, enabling better forming results.
PRODUCT SPECIFICATIONS
| Pleating Width | ≤800mm |
| Pleating Height Range | 10-100mm |
| Speed | ≤80 pleat/min |
| Supply Voltage | 380v/50hz |
| Air Source | 0.6Mpa |
|
Heating Temperature |
Normal-200℃ |
| Heating Power | 6kw |
| Motor Power | 1.1kw |
| Gross Weight | 800kg |
| Dimension | 1435x1400x1400mm |
HOW IT WORKS
CERTIFICATIONS
COOPERATE PARTNERS
ABOUT US
Bengbu Letai Filter Equipment Co.,Ltd is a professional company specializing in the development,design,production and sales of filter equipment.
The main products are hosuhole purification,industrial purification,water filtration,dust filtration,industry without partition,with partition filter production equipment.
The main equipment is automatic 300 folding height no partition origami production line,high temperature and high temperatuyre resistant glass fiber origami production line,
automatic knife origami production line,PP origami gluing high folding high climbing gluing production line,automatic air conditioning filter element welt fitting machine,origami machine and so on.
The company has senior technical personnel with more than 10 years of rich experience,the development of more than 30 kinds of product.
And will further develop advanced,practical and efficient modelsacording to the actual production in the industry,pay attention to the domestic and international trends,and make relevant contributionsto the filtration and filter industry in China and the world.
WHY CHOOSE US
10000 square meters work shop
The factory has sufficient stock supply
24 hours technical and after sales service
Professional maintenance and provision of various accessories
